Real-Time Forex Trading Bot: Design, Implementation, and Architecture

Introduction

This report presents the complete implementation, architecture, and functionality of a real-time Forex Trading Bot. The goal was to build a fully modular, object-oriented trading system capable of:

• Fetching real market data in real time
• Processing market data through a trading strategy
• Managing risk and calculating position sizes
• Simulating trades via a paper broker
• Displaying market data, positions, and logs through a GUI
• Coordinating all components via a central controller

The system uses Yahoo Finance for data, a Moving Average Crossover Strategy, a PaperBroker for simulated execution, and a Tkinter GUI with live Matplotlib charts. This project demonstrates the full lifecycle of designing quantitative trading systems using Encapsulation, Inheritance, Polymorphism, Abstraction, and Composition.

---

Objectives

• Design an end-to-end algorithmic trading simulation using OOP
• Fetch and process Forex candle data in real time
• Implement a trading strategy that opens/closes positions automatically
• Simulate PnL (profit and loss), trade execution, and position sizing
• Build a graphical interface showing:
  • Live chart of prices
  • Logs of trades
  • Current open positions

---

Modules

1. config.py

Stores system-level constants:

• Trading symbol (EURUSD=X)
• Candle refresh interval
• Initial account balance
• Max allowed position size as a % of equity
• Strategy parameters (fast MA, slow MA)

Demonstrates encapsulation by centralizing tunable parameters.

---

2. models.py

Defines data structures for:

• Candle – Represents OHLCV market data
• Order – Stores executed order details (side, price, size, timestamp)
• Position – Tracks open long/short exposure and unrealized PnL

These abstractions hide internal representation and standardize component communication.

---

3. yahoo_data_provider.py

A real-time market data provider using yfinance:

• Polls Yahoo Finance every BAR_SECONDS
• Converts data to Candle objects
• Emits new candles to subscribed callbacks

---

4. strategy.py

Defines the strategy base class and the implemented strategy.

StrategyBase (Abstract Base Class)

• Uses Python’s ABC module
• Defines required method: on_candle()
• Provides candle storage through CandleSeries

MovingAverageCrossStrategy

• Computes SMA (fast) and SMA (slow)
• Generates buy/sell signals on crossings
• Tracks last signal to avoid duplicates

---

5. risk_manager.py

Prevents oversized exposure and adjusts position size with equity changes:

\text{size} = \frac{\text{equity} \times \text{MAX_POSITION_PERCENT}}{\text{price}}

Controls position sizing dynamically.

---

6. broker.py

Simulated broker executing market orders instantly:

• Maintains account balance
• Tracks open positions
• Updates unrealized PnL
• Stores trade history
• Handles long/short flips

---

7. gui.py

Graphical interface using Tkinter + Matplotlib:

• Start/Stop buttons
• Live price chart
• Real-time logging console
• Position info display

Architecture Notes

• GUI polls get_state_callback() only on state change
• Prevents spamming position updates every second
• Displays candle closes as a line chart
• Renders positions and P&L logs

---

8. Main.py

Central controller (“brain”) of the system:

• Integrates all modules
• Handles incoming candle data
• Coordinates strategy signals
• Routes orders through the risk manager and broker
• Updates GUI state in real time

Event Flow inside on_candle():

1. Strategy receives new candle
2. Strategy evaluates buy/sell/hold
3. Broker updates unrealized PnL
4. Risk Manager determines position size
5. Broker executes the market order
6. GUI displays updated prices and PnL

---

Challenges and Solutions

1. Real-time Yahoo Finance latency

   • Irregular API caused missing or duplicate candles
   • Fixed using timed loop and retry mechanism

2. GUI freezing due to blocking operations

   • Data provider moved to background thread
   • GUI now polls state only → Tkinter freezing resolved

3. Strategy sensitivity

   • Fast MA=1 reacted too strongly
   • Adjusted slow MA to 20
   • Prevents excessive flip-flopping

4. Thread safety

   • PaperBroker uses threading.Lock
   • Prevents race conditions during order placement

---

Code Flow & Output

The system successfully fetches, processes, and executes trades while updating the GUI in real time. PnL, trade logs, and position states are displayed continuously.

---

Conclusion

This project demonstrates the successful design and implementation of a real-time Forex Trading Bot that integrates:

• Data acquisition
• Strategy execution
• Risk management
• Trade simulation
• Graphical visualization

The system can be extended further by:

• Adding multiple strategies (e.g., RSI, Bollinger Bands, ML-based signals)
• Supporting multiple currency pairs and asset classes
• Implementing realistic order types (limit, stop, partial fills)
• Connecting to live brokers for actual trading
• Enhancing the GUI with performance dashboards and analytics
• Storing trade history and equity curves in a database

This framework mirrors real-world quantitative trading pipelines and provides a foundation for advanced algorithmic trading systems.

---

References

• GitHub Project Code
• Yahoo Finance API
